Inductance is a crucial property in electrical engineering and physics, as it refers to the ability of a coil or circuit to store energy in a magnetic field when an electric current flows through it. Accurately measuring inductance is vital for designing efficient electrical circuits and components. This article explores various methods to measure inductance, practical considerations, and additional insights to enhance your understanding.

What is Inductance?

Inductance, denoted by the symbol ( L ), is measured in henries (H). It signifies the relationship between the change in current flowing through a conductor and the resulting induced voltage across that conductor. In simple terms, inductance tells us how effectively a coil can store energy in a magnetic field.

Common Units of Inductance

Microhenries (µH): ( 1 µH = 10^{-6} H )
Millihenries (mH): ( 1 mH = 10^{-3} H )
Henries (H): ( 1 H = 1 H )

Methods to Measure Inductance

1. Using an LCR Meter

An LCR meter (which measures inductance ( L ), capacitance ( C ), and resistance ( R )) is one of the simplest and most common methods to measure inductance. Here's how it works:

Connect the Component: Connect the inductor or coil to the LCR meter.
Select the Inductance Mode: Choose the inductance measurement mode on the meter.
Read the Value: The device will display the inductance value directly.

Advantages of LCR Meters

High accuracy
Quick results
Multiple parameter measurements

Limitations of LCR Meters

Expensive compared to other methods
Requires calibration for precise measurements

2. Resonant Frequency Method

This method involves creating a resonant circuit with a known capacitor and the inductor to be measured. The formula for calculating inductance ( L ) is derived from the resonant frequency ( f ) of the LC circuit:

[ L = \frac{1}{(2\pi f)^2 C} ]

Where:

( f ) = resonant frequency in hertz
( C ) = capacitance in farads

Steps to Measure Inductance Using Resonant Frequency

Build the Circuit: Connect the inductor and a capacitor in series or parallel.
Find the Resonant Frequency: Use an oscilloscope to find the frequency at which maximum current flows.
Calculate Inductance: Plug the values into the formula above.

3. AC Bridge Method

The AC bridge method is a more sophisticated technique that compares the unknown inductance with a known standard. Commonly used bridges include the Maxwell-Wien bridge and the Anderson bridge.

Procedure

Setup the Bridge: Connect the inductor, standard inductor, and resistors to form a bridge circuit.
Balance the Bridge: Adjust the known parameters until the bridge is balanced (i.e., no current flows through the galvanometer).
Calculate Inductance: Use the bridge formula to calculate the unknown inductance.

Practical Example

Suppose you want to measure a coil's inductance. You have an LCR meter at hand:

Connect the coil leads to the LCR meter.
Set the device to inductance mode.
Read the display, which shows the inductance value, say ( 150 µH ).

With this measurement, you can now consider how this coil fits into your circuit design. If designing a filter, this inductance value helps select suitable capacitors to achieve the desired cutoff frequency.

Additional Considerations

Temperature Effects

Inductance can vary with temperature due to changes in material properties. It is essential to measure inductance at a consistent temperature for accurate results.

Frequency Dependence

The inductance can also change with frequency, especially for air-core inductors versus ferrite-core inductors. Therefore, specify the frequency during measurement.

Non-linear Effects

In some applications, especially with high current or saturation levels, inductance may not remain linear. Be aware of this when designing circuits that operate under varying conditions.

Conclusion

Understanding how to measure inductance is essential for anyone working with electrical circuits. Whether using an LCR meter, resonant frequency, or AC bridge method, each technique has its advantages and limitations. By applying these methods accurately and considering practical factors such as temperature and frequency, you can effectively design and implement various electronic applications.
