Understanding Glulam Beam Span Tables: A Comprehensive Guide

Glulam beams, engineered lumber created by bonding together layers of wood, offer exceptional strength and versatility. They are commonly used in a variety of construction projects, from residential homes to commercial buildings. But how do you determine the correct span for a glulam beam? This is where glulam beam span tables come in.

What is a Glulam Beam Span Table?

A glulam beam span table is a valuable resource for architects, engineers, and builders, providing pre-calculated data on the maximum span a glulam beam can support based on its size, grade, and loading conditions. These tables are essential for ensuring structural integrity and safety in any construction project.

Key Factors to Consider When Using a Glulam Beam Span Table:

1. Beam Size and Grade: Glulam beams are available in various sizes and grades, each with different strength characteristics. The table will indicate the maximum span for each specific size and grade.

2. Loading Conditions: The table will specify the maximum load that the beam can support, taking into account factors like:

   • Dead Load: Weight of the beam itself and any permanent elements attached to it.
   • Live Load: Weight of people, furniture, or other movable objects.
   • Snow Load: Weight of accumulated snow on the roof.
   • Wind Load: Force exerted by wind on the structure.

3. Span: This refers to the horizontal distance between the supports of the beam. The table will show the maximum span for different loading conditions and beam specifications.

How to Use a Glulam Beam Span Table

1. Identify the beam size and grade: Determine the width, height, and grade of the glulam beam you intend to use.

2. Determine the loading conditions: Calculate the total dead load, live load, snow load, and wind load that the beam will be subjected to.

3. Locate the appropriate table: Find the table that corresponds to the specific glulam beam size, grade, and loading conditions.

4. Read the maximum span: The table will show the maximum span for that specific beam and loading scenario. Ensure the chosen beam span is less than or equal to the maximum span indicated in the table.

Example: Using a Glulam Beam Span Table

Let's say you are designing a roof structure for a residential home. You have chosen a glulam beam with the following specifications:

• Size: 6x12 inches
• Grade: Douglas Fir-Larch (DF-L) No. 1
• Dead Load: 20 psf (pounds per square foot)
• Live Load: 40 psf
• Snow Load: 30 psf

You would then consult a glulam beam span table for DF-L No. 1 grade, 6x12 inch beams and find the maximum allowable span under the combined loading conditions. If the table shows a maximum span of 20 feet for your chosen conditions, you can safely use this beam for a span up to 20 feet.

Beyond the Table: Additional Factors

While glulam beam span tables are valuable resources, they are not always all-encompassing. It's crucial to consider other factors like:

• Deflection: The amount of bending in the beam under load. It's important to ensure that deflection remains within acceptable limits to prevent structural damage.
• Shear: The force exerted parallel to the grain of the wood. Glulam beams are generally strong in bending but may require additional support for high shear forces.
• Beam End Conditions: The way the beam is supported at its ends (fixed, pinned, etc.) can affect the maximum allowable span.

Always consult a qualified engineer: For complex projects or when dealing with high loads, always consult a structural engineer to ensure the chosen glulam beam size and span meet all safety and code requirements.

Benefits of Using Glulam Beams:

• High Strength: Glulam beams offer exceptional strength due to their laminated construction, making them suitable for long spans and heavy loads.
• Versatility: They can be customized to different sizes and shapes to suit various architectural designs.
• Durability: Glulam beams are resistant to rot, decay, and insect damage.
• Aesthetic Appeal: The natural wood grain of glulam beams adds a warm and attractive aesthetic to any structure.

Finding Glulam Beam Span Tables:

Glulam beam span tables are available from various sources, including:

• Glulam Manufacturers: Most glulam manufacturers provide comprehensive tables on their websites.
• Engineering Software: Software programs like RISA or STAAD allow you to generate custom tables based on specific loading conditions.
• Construction Codes: Building codes often include guidelines for glulam beam design and span calculations.

Conclusion:

Glulam beam span tables are essential tools for anyone working with glulam beams. By understanding how to use these tables and considering additional factors like deflection and shear, you can ensure the structural integrity and safety of any construction project. Always remember to consult a qualified engineer for complex projects or when dealing with high loads.
